Specifications

• Dimensions

  add remove
  • Length:
    92.3 in
  • Rake (steering head):
    25
  • Trail:
    4.3 in
  • Wheelbase:
    62.4 in
  • Tires, front specifications:
    120/70R19 60V
  • Tires, rear specifications:
    170/60R17 72V
  • Fuel Capacity:
    5.6 gal
  • Oil capacity:
    4.75 qt.
  • Weight, as shipped:
    626 lbs
  • Weight, in running order:
    659 lb
  • Luggage capacity – volume:
    4.24 cu ft (0.12 m³)
  • Tire, type:
    Michelin® Scorcher “Adventure”, Radial
• Engine

  add remove
  • Engine:
    Revolution® Max 1250
  • Bore:
    4.1 in
  • Stroke:
    2.8 in
  • Displacement:
    76.40 in³
  • Compression ratio:
    13.0:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-into-1-into-1; catalyst in header
• Performance

  add remove
  • Engine torque testing method:
    J1349
  • Engine torque:
    95.1 ft-lb
  • Engine torque (RPM):
    6750
  • Lean angle, right (deg.):
    42
  • Lean angle, left (deg.):
    42
  • Fuel economy testing method:
    Estimated City/Hwy
  • Fuel economy:
    46 mpg (5.1 l/100 km)
• Powertrain

  add remove
  • Primary drive:
    Gear, 49/89 ratio
  • Gear ratios (overall) 1st:
    13.11
  • Gear ratios (overall) 2nd:
    9.687
  • Gear ratios (overall) 3rd:
    7.509
  • Gear ratios (overall) 4th:
    6.057
  • Gear ratios (overall) 5th:
    5.08
  • Gear Ratios (overall) 6th:
    4.436
• Chassis

  add remove
  • Front fork:
    47mm inverted fork with electronically adjustable semi-active damping control and Adaptive Ride Height (ARH). Aluminum fork triple clamps
  • Rear shocks:
    Linkage-mounted monoshock with automatic electronic preload control and semi-active compression & rebound damping and Adaptive Ride Height (ARH)
  • Wheels, front type:
    Annodized aluminum tubeless laced
  • Wheels, rear type:
    Annodized aluminum tubeless laced
  • Brakes, type:
    Front: dual rotor, floating, tower- mounted; Rear: solid uniform expansion rotor
  • Brakes, caliper type:
    Front: radially mounted, monoblock, 4-piston caliper; Rear: floating, single piston caliper
• Infotainment

  add remove
  • Screen size:
    6.8 in
  • Type:
    Color TFT w/ Touch
  • Headset specifications (if equipped):
    Bluetooth
  • Languages:
    Arabic, Chinese, (Simplified/Traditional), Czech, Danish, Dutch, English (default), Finnish, French (Canada/France), German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Portugal/Brazil), Indonesian, Russian, Slovak, Spanish
  • Hands-free mobile phone — via Bluetooth:
    Standard
  • Voice Recognition Languages: Phone functions only:
    Phone dependent
  • Voice Recognition Languages: Tuner / Media / Navigation:
    Phone dependent
  • Text-to-Speech (TTS) languages:
    Phone dependent
  • Rider / passenger intercom:
    Headset function only
  • Vehicle information screen:
    TPMS, Engine temp, Battery Voltage, Ambient Air Temp
  • USB:
    Charging and Instrument update, USB-C, 5V, 3A
  • Bluetooth:
    Phone/Media Supported
